Chord Mojo 2 DAC

Marknadens kanske bästa och pupuläraste portabla DAC/hörlursförstärkare.

The British designed and built Mojo 2 is the most advanced portable DAC and headphone amplifier in the world today.

Entirely engineered around a powerful, custom-coded FPGA processor, Mojo 2 benefits from several unique technologies.

Central to the new Mojo 2 is the world’s first lossless DSP, an advanced ‘digital tone control’ without any degradation in sound quality. The ‘UHD DSP’ gives Mojo 2 unrivalled compatibility with today’s wide-ranging headphones, plus unparalleled flexibility with partnering equipment.

A further key feature is the new menu system, navigated via the new (fourth) control sphere, bringing mute, crossfeed, button-lock and tone control adjustment.

Mojo 2 offers greatly improved battery management, with faster charging rates, a huge 75 % reduction in power loss, plus a 9 % capacity gain.

A new USB-C data input adds greater flexibility, transparency has been greatly boosted, thanks to an improved noise-shaper, lower distortion and greater neutrality, plus Mojo 2 can even be taken wireless with the Poly streamer/server.

Handmade in the UK with a robust CNC-milled aircraft grade aluminium chassis, Mojo 2 offers unrivalled performance, class-leading sound and peerless build quality.

Specifikationer

Fem digitala ingångar

• koaxial
• dubbeldatakoax
• optisk
• Micro-USB
• USB-C

Dynamiskt område

• 125 dB A wt.

Buller 2,7 uV A wt.

• ingen mätbar bullergolvmodulering

Distorsion och brus

• 0,0003 % vid 2,5 V 300 ohm

Uteffekt 1 % distorsion

• 90 mW 300 ohm (5,2 V RMS)
• 600 mW 30 ohm (4,2 V RMS)

Utgångsimpedans

• 0,06 ohm

Stereoseparation vid 1 kHz 300 ohm 2,5 V

• 118 dB

Mått

• 83 mm (3,26 tum) x 62 mm (2,44 tum) x 22,90 mm (0,90 tum)

Vikt

• 185 g (0,4 lbs)

Signal till brus

• 123dB 'A' viktad

Frekvensgång

• 7Hz -20kHz + / – 3dB
